Pro Import drag racing cams to suit engines making 1200hp-1600hp. Turbo sizing 72mm+. Best suited for alcohol fuels. Can run to 50psi+ boost and 10,500rpm when used with KVS18-K spring kit. Primary lobe spec: Intake: 270°/11.0mm | Exhaust: 262°/10.0mm
B16A/B18C VTEC
284/280 | B16A B18C VTEC NA
SKU:
176-B
USD $679.00Stage 1: The 176-B VTEC lobes open up top end power in the 5.5k-9.5k rpm range for track use or spirited driving. Improved power over OEM Type R cams.
294/286 | B16A/B18C VTEC N/A
SKU:
176-C
USD $679.00Suits engines with high compression, ported cylinder head and good intake and exhaust systems. Large low lobe spec for strong mid-range power.
304/298 | B16A/B18C VTEC
SKU:
176-R1
USD $679.00Drag racing cams for extreme NA engines making 250hp-300hp+. Cylinder head modifications are required. Ideal for big bore and long stroke engines.
284/274 | Stage 2 B16A/B18C VTEC
SKU:
176-T
USD $679.00Stage 2 turbo cams for engines making 600-1000hp. Turbo sizing 54-68mm. Primary lobes will crossover to VTEC around 5k rpm, VTEC will pull to around 10k rpm
274/274 | B16A/B18C VTEC Stage 1 Turbo
SKU:
176-TS
USD $679.00350-600hp engines. Suits 48-58mm size turbo. Valve timing of primary and VTEC lobes is optimised for turbo setups. Produce a broader power band compared to OEM cams.
294/298 | B16A/B18C VTEC Pro Import Turbo
SKU:
176-T2
USD $679.00Pro Import drag racing cams to suit engines making 1200hp-1600hp. Turbo sizing 72mm+. Best suited for alcohol fuels. Can run to 50psi+ boost and 10,500rpm.
